Setup Eventing with OpenShift Service Mesh

Prerequisites

You have access to an OpenShift account with cluster administrator access.
You have created a project or have access to a project with the appropriate roles and permissions to create applications and other workloads in OpenShift.
Install the OpenShift Service Mesh Operator and create a ServiceMeshControlPlane resource in the istio-system namespace. If you want to use mTLS functionality, you must also set the spec.security.dataPlane.mtls field for the ServiceMeshControlPlane resource to true.

Using OpenShift Serverless with Service Mesh is only supported with OpenShift Service Mesh version 2.0.5 or later.
Install the OpenShift Serverless Operator.
Install the OpenShift CLI (oc).

Procedure

Add the namespaces that you would like to integrate with Service Mesh to the ServiceMeshMemberRoll object as members:
```
apiVersion: maistra.io/v1
kind: ServiceMeshMemberRoll
metadata:
  name: default
  namespace: istio-system
spec:
  members: (1)
    - knative-serving
    - knative-eventing
    - <namespace>
```
1 A list of namespaces to be integrated with Service Mesh.

This list of namespaces must include the knative-serving and knative-eventing namespaces.
Apply the ServiceMeshMemberRoll resource:
```
$ oc apply -f <filename>
```

Create the necessary gateways so that Service Mesh can accept traffic:

Example knative-local-gateway object using HTTP

apiVersion: networking.istio.io/v1alpha3
kind: Gateway
metadata:
  name: knative-ingress-gateway
  namespace: knative-serving
spec:
  selector:
    istio: ingressgateway
  servers:
    - port:
        number: 443
        name: https
        protocol: HTTPS
      hosts:
        - "*"
      tls:
        mode: SIMPLE
        credentialName: <wildcard_certs> (1)
---
apiVersion: networking.istio.io/v1alpha3
kind: Gateway
metadata:
 name: knative-local-gateway
 namespace: knative-serving
spec:
 selector:
   istio: ingressgateway
 servers:
   - port:
       number: 8081
       name: http
       protocol: HTTP (2)
     hosts:
       - "*"
---
apiVersion: v1
kind: Service
metadata:
 name: knative-local-gateway
 namespace: istio-system
 labels:
   experimental.istio.io/disable-gateway-port-translation: "true"
spec:
 type: ClusterIP
 selector:
   istio: ingressgateway
 ports:
   - name: http2
     port: 80
     targetPort: 8081

1	Add the name of the secret that contains the wildcard certificate.
2	The `knative-local-gateway` serves HTTP traffic. Using HTTP means that traffic coming from outside of Service Mesh, but using an internal hostname, such as `example.default.svc.cluster.local`, is not encrypted. You can set up encryption for this path by creating another wildcard certificate and an additional gateway that uses a different `protocol` spec.

Example knative-local-gateway object using HTTPS

apiVersion: networking.istio.io/v1alpha3
kind: Gateway
metadata:
  name: knative-local-gateway
  namespace: knative-serving
spec:
  selector:
    istio: ingressgateway
  servers:
    - port:
        number: 443
        name: https
        protocol: HTTPS
      hosts:
        - "*"
      tls:
        mode: SIMPLE
        credentialName: <wildcard_certs>

Apply the Gateway resources:
```
$ oc apply -f <filename>
```

Install Knative Serving by creating the following KnativeServing custom resource, which also enables the Istio integration:

apiVersion: operator.knative.dev/v1beta1
kind: KnativeServing
metadata:
  name: knative-serving
  namespace: knative-serving
spec:
  ingress:
    istio:
      enabled: true (1)
  deployments: (2)
  - name: activator
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: autoscaler
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"

1	Enables Istio integration.
2	Enables sidecar injection for Knative Serving data plane pods.

Apply the KnativeServing resource:
```
$ oc apply -f <filename>
```

Install Knative Eventing by creating the following KnativeEventing custom resource, which also enables the Istio integration:

apiVersion: operator.knative.dev/v1beta1
kind: KnativeEventing
metadata:
  name: knative-eventing
  namespace: knative-eventing
spec:
  config:
    features:
      istio: enabled (1)
  workloads: (2)
  - name: pingsource-mt-adapter
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: imc-dispatcher
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: mt-broker-ingress
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: mt-broker-filter
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"

1	Enables Eventing istio controller to create a `DestinationRule` for each InMemoryChannel or KafkaChannel service.
2	Enables sidecar injection for Knative Eventing pods.

Apply the KnativeEventing resource:
```
$ oc apply -f <filename>
```

Install Knative Kafka by creating the following KnativeKafka custom resource, which also enables the Istio integration:

apiVersion: operator.serverless.openshift.io/v1alpha1
kind: KnativeKafka
metadata:
  name: knative-kafka
  namespace: knative-eventing
spec:
  channel:
    enabled: true
    bootstrapServers: <bootstrap_servers> (1)
  source:
    enabled: true
  broker:
    enabled: true
    defaultConfig:
      bootstrapServers: <bootstrap_servers> (1)
      numPartitions: <num_partitions>
      replicationFactor: <replication_factor>
    sink:
      enabled: true
  workloads: (2)
  - name: kafka-controller
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-broker-receiver
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-broker-dispatcher
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-channel-receiver
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-channel-dispatcher
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-source-dispatcher
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"
  - name: kafka-sink-receiver
    annotations:
      "sidecar.istio.io/inject": "true"
      "sidecar.istio.io/rewriteAppHTTPProbers": "true"

1	The Apache Kafka cluster URL, for example: `my-cluster-kafka-bootstrap.kafka:9092`.
2	Enables sidecar injection for Knative Kafka pods.

Apply the KnativeKafka resource:
```
$ oc apply -f <filename>
```

Install ServiceEntry to make OpenShift Service Mesh aware of the communication between KnativeKafka components and an Apache Kafka cluster:

apiVersion: networking.istio.io/v1alpha3
kind: ServiceEntry
metadata:
  name: kafka-cluster
  namespace: knative-eventing
spec:
  hosts: (1)
    - <bootstrap_servers_without_port>
  exportTo:
    - "."
  ports: (2)
    - number: 9092
      name: tcp-plain
      protocol: TCP
    - number: 9093
      name: tcp-tls
      protocol: TCP
    - number: 9094
      name: tcp-sasl-tls
      protocol: TCP
    - number: 9095
      name: tcp-sasl-tls
      protocol: TCP
    - number: 9096
      name: tcp-tls
      protocol: TCP
  location: MESH_EXTERNAL
  resolution: NONE

1	The list of Apache Kafka cluster hosts, for example: `my-cluster-kafka-bootstrap.kafka`.
2	Apache Kafka cluster listeners ports.

The listed ports in spec.ports are example TPC ports and depend on how the Apache Kafka cluster is configured.

Apply the ServiceEntry resource:
```
$ oc apply -f <filename>
```

Verification

Create a Knative Service that has sidecar injection enabled and uses a pass-through route:

apiVersion: serving.knative.dev/v1
kind: Service
metadata:
  name: <service_name>
  namespace: <namespace> (1)
  annotations:
    serving.knative.openshift.io/enablePassthrough: "true" (2)
spec:
  template:
    metadata:
      annotations:
        sidecar.istio.io/inject: "true" (3)
        sidecar.istio.io/rewriteAppHTTPProbers: "true"
    spec:
      containers:
      - image: <image_url>

1	A namespace that is part of the Service Mesh member roll.
2	Instructs Knative Serving to generate an OpenShift pass-through enabled route, so that the certificates you have generated are served through the ingress gateway directly.
3	Injects Service Mesh sidecars into the Knative service pods.

Apply the Service resource:
```
$ oc apply -f <filename>
```

Access your serverless application by using a secure connection that is now trusted by the CA:

$ curl --cacert root.crt <service_url>

Example command

$ curl --cacert root.crt https://hello-default.apps.openshift.example.com

Example output

Hello Openshift!
